Use: cleaning of materials after die cutting.
Material: suitable for all kinds of packaging products, such as paper card, tag, trademark, medicine box, cosmetics box, PVC and so on.
Principles: adopting the latest hydraulic, pneumatic components, high precision wire rods, guide rails and servo motors, as well as rational mechanical PLC systems, electrical control, digital input automatic cleaning.
Technical Parameters:
Model | TM780D | TM1080D |
Maximum format (mm) | 780x540 | 1080x780 |
Maximum stack height (mm) | 60 | 60 |
Maximum scale (mm) | 780x540 | 1080x780 |
Minimum cleaning diameter (mm) | 10 | 10 |
Removal speed (fimes/min) | 2 | 2 |
Maximum pressure (bar) | 70 | 70 |
Shape dimension (mm) | 1600X1600X2000 | 1900X2100X2000 |
Machine weight (kg) | 3200 | 4000 |
Voltage (v) | 380/50Hz | 380/50Hz |
Total power (kw) | 7 | 9 |
